Description:
The light sensor switch can turn on or turn off light by automatically according to ambient-light. Ambient-temperature and humidity can not affect it. It is not only convenient but also practical; it can control the load working only at night. For instance road light, garden light etc.
Specification:
Voltage:AC220-240V 50-60Hz
Wattage:<0.1W
Current:10A
Working temperature:-40â„? to +70â„?
Light intensity:
turn on the light brightness:<30Lux
turn off the light brightness:>150Lux
Feature:
Internal circuit automatically detects environmental illumination, automatically shut down during the day and at night automatically.
Three-wire system, compatible with resistive, inductive, capacitive load multiple lights.
The control object can be energy-saving lamps, fluorescent, incandescent, exhaust fan lights.
With a time delay function when environmental conditions change.
Installation:
1.Switch off the power. Connecting the wire as per the following figure.
2.Please install the item with the correct orientation (see figure A) what shows in the metal bracket and according to the correct installation place with the enclosed inflated screws.
Package included:
1*AC220-240V light control sensor switch
