Interface Controller & CPU: PD/ VL102+HDMI chip PS176+USB conversion VL817+ Card reader GL823
Interface performance:
USB3.0 Type-A Port: *2 Data transfer 5Gb/s
USB3.1 Type-C Port: *1 Data transfer 5Gb/s PD Charge PD3.0
Card Reader Port: *1 SD card & *1, TF card
HDMI Port: *1 4K@30Hz
Material: Metal +Plastic
Indicator light: Wight LED
Color: Gary, Sliver, Gold, Rose Gold
Product Weight: 46g
Product Dimensions:116.5x28x10.9mm (w/o cable)/ Cable 154mm
Package weight: 135g
Package Dimensions:159x55x48mm
Compatible Devices:
-Laptop:
-MacBook 12inch / MacBook pro 2016 Series / MacBook pro 2017 Series
-Surface Book 2/ThinkPad S1/S2/X1 2017 Series
(In any laptop with TYPE-C interface, data transmission is supported)
-Phone:
-Samsung S8 /Samsung S8Plus /Samsung Note 8 (no support dex mode,only copy screen)
-Huawei Mate10 /Huawei Mate10pro
-Card reader and USB storage device are supported on any mobile phone with TYPE-C interface
Note:
-1: The Max Support Resolution to 3840X2160 4K@30Hz with Single Input.If you want to diaplay 4K video in your monitor,
it also need you have 4K Source,4K Cable and 4K Displays.
-2: The USB3.0 Ports allows you to connect U-Disks/Hard Disks/Mouses/Keyboards to the adapter according your requirements.
-3: This Adapter works well with your Chromebook,Macbook Pro and most of devices that support USB-C DP Alt Mode.
(Can not connect to tablets and Mobilephone, except for Samsung S8, note 8,Huawei mate10)
-4: If you connect usb-c male to your laptop's usb-c female, please make sure the USB-C male is inserted completely to the female in
the computer and tightly
-5: If you connect USB-C one side and it do not detect your laptops, Please try to use the another side to input in your computer.
-6: the TF and SD can not read/use at the same time.
More Details:
